4 sided woodworking thicknesser planer in wood planer moulder machine for sale craigslist | 4 Sided Wood Planer
4 sided woodworking thicknesser planer in wood planer moulder machine for sale craigslist | 4 Sided Wood Planer

4 sided woodworking thicknesser planer in wood planer moulder machine for sale craigslist | 4 Sided Wood Planer


Model:MB416
Processing width:25-160mm
Processing thickness:8-120mm
Feed speed:6-36m/min
Dimension(L*W*H):1400 * 900 * 1590mm
Weight (KG):310 KG
Power (kW):21.05


Details
Spare Parts
Inquiry

Heavy duty wood planer for floor, door and frame processing.  Wood Planer works give you own all the economy and efficiency of excellent performance at a reasonable price.
Model MB416
Processing width                             25-200mm
Processing thickness 8-140mm
Feed speed 6-36m/min
Spindle diameter ø40
Spindle speed 6500r/min
Air pressure 0.6Mpa
First lower axis 5.5KW/7.5HP
The first up axis 7.5KW/10HP
Right vertical axis 5.5KW/7.5HP
Left vertical shaft 5.5KW/7.5HP
Second lower shaft 5.5KW/7.5HP
Second upper shaft 5.5KW/7.5HP
Cross beam lifting 0.75KW/1HP
Feeding power 4KW/5.5HP
Right vertical axis ø125-180mm
Left vertical shaft ø125-180mm
First lower axis ø125mm
The first axis ø125-180mm
Second lower shaft ø125-200mm
 Total power 34.25KW/46.51HP


This moulder has an exclusive differential all cast iron base construction.For extraordinary precision speed and reliability. This wood planer molder is your best choice.


200mm x 125 mm moulding capacity.
Full coverage sound cover/safety enclosure is optional.
Long infeed table and fence for straightening feeding work pieces.

Electrics control are CE approved available. Manufacturer best industrial sides moulder 4 sided wood planer machineOptional Equipment Increase motor horsepower available is optional.Automatic table lubrication system.

Pneumatic pressure feed system for easy adjustments. Standard 40 mm spindles for this Industrial wood planer.
High speed cutter heads making wood piece more smoothing Cardan joint drive system with drive shafts and oil bath gear boxes.
Solid heat treated cast iron construction for long life and vibration free performance.

Replaceable chrome bed plates for easy maintenance. (Older or cheap wood planer is single table, after long time wearing, you need to change the working table, single table need to discharge cutter spindles. Hard operation and Influence accuracy)
Cast aluminium motor, has oil Automatic lubrication system, there is display to show oil stock.
Precision sealed long life high speed bearing.
Industrial full power motor for maximum cutting capacity.
WEHO Machinery is an original equipment manufacturer, all machines can be custom built to the customer requirements. We can design and manufacture most of wood processing machines. Our goal is to exceed customer expectations. We’re machine factory, but service is our business.

4 Sided Wood Planer

[]
