Automatic double end drilling wood dowel making machine
Automatic double end drilling wood dowel making machine

Automatic double end drilling wood dowel making machine


Model:MXZ1224
Working length:300-1200,300-1800,300-2400mm
Main spindle rotating:5600rpm
Saw blade spindle dia:25.4

Install power:20kw
Weight:2000


Details
Spare Parts
Inquiry

It is mainly used for the double end cutting, moulding, shape, drilling, oring, mortising and grooving  of wood to fixed length drill holes and slot or mortising and milling on double end one time processing. It can saw the bevel angle, carry out the longitudinal processing for the short material plate, mill the double end cutting tenon.
 Product name double blade drilling machine
 Working length  300-1200,300-1800,300-2400mm
 Feeding speed  Manual or Automatic
 Saw blade tilting bevel  0-45 degree
 Main spindle rotating  5600rpm
 Saw blade spindle dia  25.4
 Saw blade motor 3HP
Vertical milling cutter spindle 30,35,40 or customized
Vertical milling cutter power 3kw or 4kw, 5.5kw

Double blade circular saw, double end milling groove,milling shape, fixed length wood processing, the saw blade can be inclined 45 degree longitudinal cutting.double end cutting saw machine has solid body,good quality,wear-resistant and durable guide rail.

Automatic double head cutting saw sawing with optional spindle shaper. Head swivel for flexible and easy operationHead adjustable for up and downSliding guide withl inear bearing for easy sliding.Heavy structure for maximum stability.

 WEHO Machinery is an original equipment manufacturer, all machines can be custom built to the customer requirements. We can design and manufacture most of wood processing machines. Our goal is to exceed customer expectations. We’re machine factory, but service is our business.
