Automatic feeding three cutters make hole wood lathe machine to making wooden beads/handle/cigarette holder
Automatic feeding three cutters make hole wood lathe machine to making wooden beads/handle/cigarette holder

Automatic feeding three cutters make hole wood lathe machine to making wooden beads/handle/cigarette holder


Model:WH-38
Toos:3 cutters
Working length:15cm
Working diameter:3.8cm
Weight:400kg


Details
Spare Parts
Inquiry

New automatic feeding woodworking lathe, support round and square materials, save more labor, three turrets, can choose whether to making hole.
Model WH-3840 WH-3850 WH-3870
Feeding mode Automatic feeding Automatic feeding Automatic feeding
Working diameter 3.8cm 4.8cm 6.8cm
Maximum working length 15cm 15cm 15cm
Maximum feeding length 70cm 70cm 70cm
Manual feeding length 200cm 200cm 200cm
Machining accuracy 0.01mm 0.01mm 0.01mm
Motor power 2.2kw 2.2kw 2.3kw
Machine dimensions 2500*660*1200mm 2500*660*1200mm 2500*660*1200mm
Weight 400kg 400kg 400kg

Tail design:Scientific design, fully closed dust control, lead screw track, high production accuracy, longer service life.

Feed hole

Processing Exhibition
80 * 80 national standard square pipe, with thickness of 6mm and stable guarantee Magnetic start key position can be placed at will, vector converter can be selected
Installation position of x-axis motor
Name TBI ball screw TRH linear guide
Model SFUR16140 TRH20B
Accuracy ±0.01mm ±0.01mm
Advantage high precision, low noise, high stability High precision, low drag 3D guidance

Lead screw design: maintain the accuracy of the ball screw, reduce sawdust and dust pollution, improve the service life of more than 5 times.

CNC lathes: The whole series of CNC lathes are upgraded to CNC digital controller control, which not only saves 1 control computer, does not need USB cable connection, has strong anti-interference, is more stable, does not need mouse and keyboard, is more convenient to operate, and is more suitable for factory work, with the use of intelligent code automatic generation software.

CNC system:Import the following shape picture, input the required size and length, select the processing method and tool, the software can automatically generate the NC lathe processing program (G). The processing Diamante is directly saved to the TF card, and the lathe processing is directly controlled by the controller.

Product display




Accessories display

[]
