Automatic wood milling plastic crusher cutter chipper knife grinder paper cutting guillotine blade grinding sharpener machine
Automatic wood milling plastic crusher cutter chipper knife grinder paper cutting guillotine blade grinding sharpener machine

Automatic wood milling plastic crusher cutter chipper knife grinder paper cutting guillotine blade grinding sharpener machine


Model:MF2515AC
Max. grinding length:1500mm
Grinding wheel dimension:205*115*145mm
Wheel head rotation speed:1440r/min
Weight (KG):1800
Power (kW):7.5


Details
Spare Parts
Inquiry

Available with grinding lengths ranging from 1500 mm to 3100 mm, or longer for special grinding purposes.Grinding wheel quick up and down approach, and slow down approach.
Model
MF2515AC
Max. grinding length
1500mm
Grinding wheel dimension
205*115*145mm
Cutter rest adjustable angle
0-90°
Wheel horizontal moving speed
0-60Hz
Wheel head rotation speed
1440r/min
Main electric motor power
5.5kw
Feeding electric motor power
0.75kw
Water pump power
90w
Working table size
1500*200mm
Max. distance of wheel head horizontal lifting
200mm


Programmable work cycles: roughing, finishing, spark-out;Separate coolant collection tank fitted with 90W motor pump.Grinding motor 7.5 kW (7HP).Variable carriage speed from 1 to 30 m/min with carriage run adjustment.

It features a heavy-duty reinforced machine base which gives the maximum stability. PLC controls the carriage movement during the various stages of the working cycle.



Suitable for a broad range of industrial straight knives, such as crusher knife blade, chipper knives, granulator blades, veneer knives, guillotine blades and paper knives. Rotating magnetic chuck from 0 to 90 (Polarity 20 mm)
Milling cutter grinder grinding wood automatic plastic crusher guillotine blade planer knife sharpening machine.Automatic grinding wheel downfeed.
 35mm Linear guide rail made in Taiwan Hiwin, with sliding block , the grinding head moves more stable and precise.

Mass production for the heavy duty knife grinding machines.
[]
