China wide belt nylon brush rollers sander machine wood planer sander floor sanding for sale
China wide belt nylon brush rollers sander machine wood planer sander floor sanding for sale

China wide belt nylon brush rollers sander machine wood planer sander floor sanding for sale


Model:MF4-1800
Brushing width:1800mm
Drawing roller diameter:200mm
Plate thickness:2-110(160)mm
Power (kW):43.5
Weight (KG):3500 kg


Details
Spare Parts
Inquiry


Wire Brush-Master/Denibber,Heavy duty machine for deep, medium and light wire brushing effects.Base on different wood material and requirements, manufacture different wood brushing machine.
Usage: Solid wood grain highlighting, with steel and nylon wire brushes,WPC decking profile brushing, with steel and nylon wire brushes,Wood profile polishing and denibbing, with sandpapers .
Model MF4-1800
Brushing width 1800
plate production thickness 2-110(160)mm
Working length >=500mm
conveyor belt speed invertor control
drawing roller diameter 200mm
total motor power 43.5kw
1st motor power 11kw,6 pole
2nd motor power 11kw,6 pole
3rd  Motor power 11kw,6 pole
4th motor power 7.5kw,6 pole
conveyor belt motor 3kw
Lift table motor 400W*4pcs
working air pressure >0.55Mpa
dust collection average wind speed >=25m/s
Machine weight 3500kg


This machine is specially designed and manufactured to Centralized control panel.Manufacturing wood brushing machine over 10 years , full production experience for speical requirement.

Steel wire brush or roller, nylon brush rollers, work together or separately.Fine adjustment and digital display of table openings.Hold-down rollers and feed-in table height adjustment.

Hold-down rollers and feed-in table height adjustment Rotate speed of the brush and feed speed controlled by inverter Modular configuration Easy exchange of brushes .

Max.working width include: 600mm:800mm:1000mm:1300mm:1600mm 1800mm and so on.Working length:more than 400 mm.

Modular configuration:Variable diameters,either of rollers or steel wires, and brushing configuration optional,Easy exchange of brushes,

Max. working width include:400 600mm; 800mm;1000mm;1300mm;1600mm or others.The stainless wire brush mainly to remove the soft grain and nylon-wire brush mainly to clean the panel surface.

Machine features: Centralized control panel Steel wire brush or roller, nylon brush rollers or vertical wire disc, work together or separately Fine adjustment and digital display of table openings.

WEHO Machinery is an original equipment manufacturer, all machines can be custom built to the customer requirements. We can design and manufacture most of wood processing machines. Our goal is to exceed customer expectations. We’re machine factory, but service is our business.
wood planer sander
[]
