CNC 5 side dowel wood cabinet carving drill plywood door making hinge boring drilling machine | Plywood Drilling Machine
CNC 5 side dowel wood cabinet carving drill plywood door making hinge boring drilling machine | Plywood Drilling Machine

CNC 5 side dowel wood cabinet carving drill plywood door making hinge boring drilling machine | Plywood Drilling Machine


Model:CD1200
Max.Working Width:50-1000mm
Main motor rotatiing:18000rpm
Dimension(L*W*H):2400*2200*1600mm
Weight (KG):2000 KG
Power (kW):7.5


Details
Spare Parts
Inquiry

 Boring holes from 5 sides of wood panel, four sides holes boring and bottom face boring holes,  boring position set from cnc program, control system is Taiwai SYNTEC, working high efficient and convient for operation.
Model CD1200
CNC wood boring machine

working speed
X axis max moving speed m/min 70
Y axis max moving speed m/min 70
D axis max moving speed m/min 30


CNC wood boring machine working size
Minimum panel width mm 60
Max panel width mm 1000
Effective panel width mm 800


CNC wood boring machine working length
Minimum panel length mm 300
Max thickness mm 50
min thickness                             mm                 10








Plywood Drilling Machine
[]
