CNC vertical band saw machine for  making sofa chairs and tables for woodworking machine | woodworking band saw machine
CNC vertical band saw machine for  making sofa chairs and tables for woodworking machine | woodworking band saw machine

CNC vertical band saw machine for making sofa chairs and tables for woodworking machine | woodworking band saw machine


Model:MJS1212
Max.Working Width(mm):
760 mm
Max.Size of workpiece:1200*1200mm
Max.working thickness:150mm
band Saw wheel diameter:760mm
band saw blade length:5430x13x0.9mm
Min.cutting radius:R80 orR95mm
Saw tilting:±90
Power (kW):7.5


Details
Spare Parts
Inquiry

1) The processing efficiency is high, the processing work-piece surface is good quality and no need to be crossed.
2) Save the timber, processing range is wide, automatic programming, the operation is easy, man-machine division, it can reduce the risk of industrial injury, it is an ideal production equipment for wood furniture and other enterprises.Fast connect feeding table saw and main cutting band saw
SPECIFICATIONS For woodworking vertical cnc band saw machine

Working size
Max working length and width
mm
1200x1400
Max Thickness
mm
150
Band saw blade size
mm
5430x13x0.9

Main performance parameters
Working speed
m/min
1-15
Saw blade Rotating angle
°
+90 -90
Cutting power
HP
10


Machine size
Dimensions
mm
3800x3200x2600
Weight
KG
4300
Cast iron wheel
mm
760x60
This cnc bandsaw no need to rotate the saw blade, it can easily rotate 90' , and the used saw range is wide,  scientific structure design avoids the loss brought by the saw breaking and loss, extend the life of the saw blade.



The open feeding platform is more convenient, and the sawing efficiency is higher.

Strong cylinder fixtures, the clamping device is reliable, clamping range is wide, it can saw the multi-layer sheet synchronously.The saw clamping device can enhance its precision.

CNC band saw machine is an affordable and economy machine, it can solve the curve processing for hundreds of users.

woodworking vertical cnc band saw machine.Strong clamper for push workpieces.safety door to provent accident.Cast aluminium wheel.









Cnc Band Saw Machine
woodworking band saw machine
[]
