CNC woodworking wood lathe for wooden bead/wooden plates/wooden bowls making machine | Wood Lathe Machine
CNC woodworking wood lathe for wooden bead/wooden plates/wooden bowls making machine | Wood Lathe Machine

CNC woodworking wood lathe for wooden bead/wooden plates/wooden bowls making machine | Wood Lathe Machine


Model:WH-9030
Tool:2 cutter
Working diameter:30cm
Working length:90cm
Weight:400kg


Details
Spare Parts
Inquiry

High precision woodworking lathe can help you make hundreds of kinds of wood products, such as sticks, bowls, cups, plates, handles, handrails, etc.
Model WH-9030
Toos 2 cutter
Working diameter 30cm
Working length 90cm
Spindle speed 0-2000rpm
Machining accuracy 0.01mm
Power 2.2kw
Size 1750*750*1080mm
Weight 400kg


Tail design:Scientific design, fully closed dust control, lead screw track, high production accuracy, longer service life.

Processing Exhibition
80 * 80 national standard square pipe, with thickness of 6mm and stable guarantee Magnetic start key position can be placed at will,brake motor, emergency stop and start.
Installation position of x-axis motor
Name TBI ball screw TRH linear guide
Model SFUR16140 TRH20B
Accuracy ±0.01mm ±0.01mm
Advantage high precision, low noise, high stability High precision, low drag 3D guidance

Lead screw design: maintain the accuracy of the ball screw, reduce sawdust and dust pollution, improve the service life of more than 5 times.

CNC lathes: The whole series of CNC lathes are upgraded to CNC digital controller control, which not only saves 1 control computer, does not need USB cable connection, has strong anti-interference, is more stable, does not need mouse and keyboard, is more convenient to operate, and is more suitable for factory work, with the use of intelligent code automatic generation software.

CNC system:Import the following shape picture, input the required size and length, select the processing method and tool, the software can automatically generate the NC lathe processing program (G). The processing Diamante is directly saved to the TF card, and the lathe processing is directly controlled by the controller.

Product display


Product size

Accessories display


Wood Lathe Machine

[]
