Sand belt bend wood double side polishing machine
Sand belt bend wood double side polishing machine

Sand belt bend wood double side polishing machine


Model:MM320P
Max working width:150mm
Max Working thickness:100mm
Min Length:360mm
Power:4kw


Details
Spare Parts
Inquiry


This production line solves the problem of sanding / chamfering / polishing of the surface of dining chair, and basically meets the requirements of the sanding surface to be flat, without waves, and no chamfers. The finished front feet can be directly painted or primed.
Model MM320P
Max working width 150mm
Max working thickness 100mm
Min working length 360 mm
Sanding motor 1.5KW*2 with invetor
Feeding motor 0.25KW*4
Feeding speed 3-15m/min(Frequency )
Sanding belt size 140×1200 mm
Sanding wheel size φ170×150
Dust output φ100*2
Table height 92cm
Weight 280Kg
Overall size 1100×920×1230 mm


Spring positioning structure for wood sander machine, fast, accurate and easy to learn, reduce failure rate.Closed dust suction structure, no flying dust, more environmentally friendly.

The belt is equipped with air blowing heat dissipation, which can effectively extend the life of the belt and reduce the cost of consumables.

The main shaft adopts original imported NSK high sealed bearings.The sand belt movement adopts the air-feeding structure, which is more stable and guarantees the sanding quality.

WEHO Machinery is an original equipment manufacturer, all machines can be custom built to the customer requirements. We can design and manufacture most of wood processing machines. Our goal is to exceed customer expectations. We’re machine factory, but service is our business.
