Upvc aluminum window frame making machine for door fabrication | Window Making Machine
Upvc aluminum window frame making machine for door fabrication | Window Making Machine

Upvc aluminum window frame making machine for door fabrication | Window Making Machine


Model:MJL90;MJL90A
Circular saw blade size:405/455mm
Max cutting height:140mm
Max cutting Width:290mm
Weight:280kg


Details
Spare Parts
Inquiry

Suitable for cutting aluminum materials , processing aluminum doors and windows materials, curtain wall materials, industrial materials and other aluminum metal materials.
Model MJL90
Motor power 3HP
Circular saw blade size 405mm or 455 mm
Max cutting height 140mm
Max cutting Width 290mm
Overall dimension 870*670*1350mm
Machine weight 280kg


Aluminum cut off saw adopts pneumatic cylinder liquid oil to promote feed, fast speed, quick and stable for cutting saw blade return back, adjustable speed of cutting machine, table surface machining by flat grinding machine, high precision and stable performance, saw blade with automatic spray cooling device, has longer service life.

Apply to cut 90 degree for aluminum door materials, window materials, fixed 90 degrees positioning, angle deviation can be adjusted according to the processed aluminum profile.

The worktable installed with air cylinder. Air pressure and pressing speed are adjustable, according to thickness of the material, adjust it to the appropriate working pressure and speed to avoid damage aluminum profile and make it deformed.

The foot pedal start cutting design of cutting, which avoids the insecurity of manual cutting, and the pneumatic pushing cutting is stable, the cutting plane is smooth and burr free, the cutting speed is fast, safe and reliable

WEHO Machinery is an original equipment manufacturer, all machines can be custom built to the customer requirements. We can design and manufacture most of wood processing machines. Our goal is to exceed customer expectations. We’re machine factory, but service is our business.
