Woodworking multi blade table circular rip saw machine for sale
Woodworking multi blade table circular rip saw machine for sale

Woodworking multi blade table circular rip saw machine for sale


Model:MJ600-XD4
Saw blad diameter:255mm
Raw panel thickness:5-50mm
Max width of raw panel:600mm
Feeding speed:0-15m/min


Details
Spare Parts
Inquiry

The Multi-blade Panel Saw has been devised for executing cuts and multiple grooves on boards, also with veneered surfaces and coated with various materials.
Model MJ600-XD4
Saw blad diameter 255mm
Main spindle motor power 22kw
Feeding speed 0-15m/min
Feeding power 3kw
Raw panel thickness 5-50mm
Max width of raw panel 600mm
Active bottom rubber roller 8 pcs
Passive top rubber roller 8pcs
Feed board width ≥400mm
Oversize 2830*1230*1530mm


It is realized in various powers and with working width capacity of 80, 130, 160, 190, 250 o 310 cm, the MLS can be supplied with special equipment, according to the production requirements of the customer, and also in the version TR, for transversal grooves and cuts.

For the processing of fiberboard,laminated wood,soild wood and so son,also it can work out different depth on the same worpicec.(Door frame board,moulding,etc.)

The machine features a precise and compact tubular steel structure, which gives to the unit an high sturdiness and, moreover, it is equipped with:
- electronic adjustment of the advancement speed;
- regulation system of the passage opening among the rollers of the advancement group, according to the panels thickness;
- safety system for panels thickness control;

- regulation system of the cutting and grooving depth, without changing the working table height with respect at the floor;
- advancement group of the workpieces through rollers, with opening by a pneumatic cylinder for permitting the tools change on the spindle;

It is a machine with an high efficiency, which is used with excellent results for the production of prefinished parquet, walls and ceilings, doors for furniture, strips for profiles, staves for beds, MDF frames and so on.


circular rip saw machine
[]
